Fiche Technique:
- 4.3" FSTN display
- Resolution: 192x64 pixels (4 x20 characters)
- Brightness 97 cd/m2
- 8 bit CPU
- Memory 64KB FLASH ROM
- Non-volatile 2KB EEPROM
- Digitizer: No
- Function keys: 19 programmable keys
- LED backlight
- Case color:silver white
- Protection sign: IP65 (front bezel)
- Rated power: 3.6W
- Voltage range: 21~28V DC
- Fanless cooling
- Insulation resistance Greater than 10 megohms at 500V DC
- Radioelectric immunity Voltage 1500Vp-p, Pulsecycle 1µs, duration 1µs
- Dielectric rigidity: 500VAC 1 minute
- Operating température: 0~50℃
- Storage température: -20~70C
- Operating humidity: 20~90% (non-condensing)
- Shock resistance 10~25Hz (X,Y,Z direction, 2G, 30 minutes)
- case material: PC+ABS
- Cutout: (mm) 165x78
- Dimensions (mm) 175x90x26
- Display dimensions: 101x36
Accessories
Your Dynamic Snippet will be displayed here... This message is displayed because you did not provided both a filter and a template to use.
Specifications
| Brand | Kinco |
| Voltage | 24 V |
| Screen size | 4.3 pouces |
